It’s time for automated processes to become a whole lot smarter

Smart, interconnected factories can help process and manufacturing industries from any sector to boost their productivity, efficiency, product quality and consistency.

A recent analysis from Deloitte and the Manufacturer’s Alliance for Productivity and Innovation (MAPI) showed how smart manufacturing initiatives can increase productivity, throughput, and factory capacity by approximately 10 percent. This is possible by having machinery and equipment that can improve industrial processes through automation, communications, and self-optimization.

To do so, large volumes of data need to be gathered from a broad range of operational technology (OT) systems, processed efficiently – ideally via edge computing, and then transmitted to top floor information technology (IT) infrastructures. Therefore, smart plants and factories need a networking technology that does more than handle increasingly greater data traffic.

The network of the future must be able to bridge IT and OT. To successfully merge field and higher enterprise levels, smart industrial networks should be able to prioritize any time-critical control messaging, as well as assign bandwidth in a faster, more controlled, and accurate manner.

All these aspects are particularly challenging for most industrial Ethernet networks currently available. Noteworthy within the field level, traditional industrial Ethernet networks often use bandwidth-hungry overprovisioning approaches to transfer both time-critical and non-urgent data.

They may also work on nonstandard “Best Effort” data delivery systems to optimize determinism. These use Class of Service (CoS) mechanisms to guarantee Best Effort bounded end-to-end latency of time-sensitive data traffic. However, CoS could also be responsible for the delay of urgent process data in these set-ups. In fact, when the transmission of a non-urgent message is underway, time-critical messages are assigned to a queue and can no longer be prioritized.

A call for change in traffic scheduling

The state-of-the-art solution required is Time-Sensitive Networking (TSN). TSN technology (Time-Sensitive Networking) can address these issues by offering an Ethernet standard that implements deterministic capabilities on an ISO/OSI (International Standards Organization/Open Systems Interconnection) Data Link Layer. More precisely, the Institute of Electrical and Electronics Engineers (IEEE) standards 802.1 governing TSN functionalities define several traffic shaping and scheduling tools that guarantee the efficient delivery of any kind of data on an Ethernet network.

Smart plants and factories need a networking technology that does more than handle increasingly greater data traffic.

A key element, defined in IEEE 802.1Qbv, is TSN’s Time-Aware Scheduler (TAS). This is a gate driver that prioritizes Ethernet frames based on their transmission time. When urgent cyclic data need to be transferred, TAS temporarily interrupts the transmission of non-urgent traffic. As a result, time-sensitive data can be delivered within the reserved time slots for high-priority traffic.

IEE802.1Qbv also specifies a length-aware scheduling mechanism to optimize bandwidth usage. When the scheduler receives a message that needs to be transmitted, the overall length of the frame is checked. If the frame can fit without affecting high priority traffic, the scheduler sends this information. If not, the message is queued or — as defined by IEEE 802.1Qbu and IEEE 802.3br — can be transmitted in two separate parts (frame pre-emption).

Thanks to these different IEEE 802.1 sub-standards and tools, TSN can enhance the reliability of traditional industrial Ethernet protocols, and tailor both bandwidth and latency based on the specific application requirements. Consequently, critical and non-critical data traffic can efficiently coexist.

For example, recent studies found that TSN could outperform TCP and other solutions maintaining extremely low latencies on highly congested networks. More precisely, it could maintain a 2 ms latency on a trunk link connecting two switches characterized by a 95 percent capacity (or congestion) even when transmitting frames with high payload sizes of 200 bytes.

Leading the way in TSN implementation

The established open industrial Ethernet technology CC-Link IE has adopted TSN. The resulting solution, CC-Link IE TSN, combines the benefit of a well-developed open Ethernet framework with Gigabit bandwidth along with the added capabilities of IEEE 802.1 TSN technologies.

Author Thomas Burke.

The system is built around ISO/OSI Layers 3 to 7 and adopts IEEE 802.1AS and IEEE 802.1Qbv standards concerning synchronization and scheduled traffic.

By choosing the CLPA and its technologies, such as CC-Link IE TSN, end users can rely on network solutions at the forefront of automation. Industries can adapt to growing manufacturing demands and more easily turn their factories into smart, interconnected systems.

Thomas Burke is Global Strategic Advisor at CC-Link Partner Association (CLPA) Americas.
